The relational database’s parking garage

So we’re building a parking garage and we assign the task to our friend the database architect. Only, he builds a parking garage unlike anything we’ve ever seen before.

When people pull their car into the garage, it is disassembled into all of its component parts and labeled with the id of the car. There’s a bin of spark plugs, and a bin of license plates, a bin a steerings wheels, … .

When someone comes and asks for their car by its license plate number, we look through the bin of license plates until we find the one they asked for. Affixed to the license plate is the id that was assigned to the car. Now we can go through all of the other bins and collect all of the rest of the parts, re-assemble the car, and deliver it to the driver.

This is what a relational database does to our data.

Sometimes a car is just a car. I can put cars in my parking garage just fine. And yes, I can still find your car by its license plate number just fine. In fact, if I keep a sheet of paper listing all of the license plates (e.g. an index) and which spot the car is in, i can find your car just as fast, if not faster, than when it was in the bin.

NoSQL Database Comparison

People often ask to compare the various NoSQL solutions. There are a number of comparisons out there, in particular there’s . But I think that many comparisons focus on details that are secondary to the concerns of most developers.

There’s a lot of focus out there on mechanisms and implementation details, and not a lot of focus on the abstract guarantees that these databases can provide. I tend to break down the various NoSQL datastores according to the data models exposed to the developer and the invariants that the system can guarantee against those data models.

You can break these down into 4 characteristics of your data store: Data Model, Consistency, Availability, and Partitioning. In this post we’ll look at the various design choices within each category and the implications of each choice.

Full disclaimer, I work for 10gen, the makers of MongoDB, and before that I operated a MongoDB cluster in production for about a year. So I have a lot more in depth knowledge of MongoDB than the other datastores discussed in this document. Please point out any inaccurate statements in the content below and I’ll happily correct it.

We’ll start with an overall picture of some of the more popular NoSQL stores and where they fit along these axes. We’ll then dig into each axes and look at the choices and what it means for our application.

NoSQL Datastore Overview

MongoDB Cassandra Riak HBase
Data Model Documents Wide Columns Key Value Wide Columns
Consistency Strong Eventual / Quorum Eventual / Quorum Strong
Availability Single Master Multi-Master Multi-Master Single Master
Partioning Range or Hash Hash Hash Range

Data Model

The data model specifies how your application will format and store data in the database and how you can query and update that data later. Most of the NoSQL data stores fall into one of a few different data model options:

Key Value

Data is modelled as opaque blobs identified by a unique identifier. Key Value stores are the simplest data models available since there’s relatively little work for the database to do. Your query language is limited to lookups by primary key, tho some vendors have extended their key value store with simple secondary indexes (eg. riak).

Key Features

  • High performance

Wide Column

Data is modelled as a multi-level map comprising a Row Key, Column Family, and Column name. This model was popularized by .

Queries must include the row key and can optionally include names of column families and columns to further restrict the query.

This is a big improvement over the key-value API in terms of query flexibility as we can now filter on column names. However, we still lack the general ability to query on values as we can in traditional SQL queries. This model works pretty good for things like time series data where you need to store lots of values associate with a stream. But it can be challenging to model business data.

Key Features

  • More flexible than key-value
  • Good at storing time series data

Document

Data is modelled as hierarchical documents that consist of name value pairs nested within each other. This could be JSON, XML or any other similar syntax, tho most document oriented stores that are popular today work off of JSON. Documents benefit from being closer a closer abstraction to the objects we use in code. You tend to be able to take object trees and serializes them as JSON directly into the database, rather than requiring a mapping layer as is typical with relational or wide-column stores.

Key Features

  • Maps closer to programming language
  • Easier to query, index

Consistency

in the context of distributed databases refers to whether two clients trying to perform operations on objects in the database see the same or conflicting views of the world. The more they see the same view, the more “consistent” we say they are. Eric Brewer’s work on the has guided much of the discussion around consistency today, pointing out that when a distributed database experiences failures, it must choose whether it wants to maintain Availability (e.g. clients can still perform operations on objects) or Consistency (e.g. clients see the same version of objects). We find that if we relax our consistency model, we can get stronger availability and vise versa.

Eventual Consistency

Eventual consistency is a relaxed consistency model typically employed in order to achieve higher availability in the database. In an eventually consistent system, writes to the database are eventually visible to to all readers. This means that if I send a write request to the database and immediately try to read, then I may not read my own write.

Key Features

  • High availability (as in, no downtime)
  • Might have inconsistent data

Strong Consistency

Strong consistency ensures that if I perform a write operation to the database, other clients are guaranteed to see my write on the very next read. Databases that provide this level of guarantee often require small periods of un-availability during failures when they are temporarily unable to enforce this level of consistency.

Key Features

  • Periods of unavailability while fail-overs happen
  • Clients can get stonger guarantees on object consistency

Availability

Intimately tied to the Consistency model of your database is the Availability model. Most NoSQl stores use one of two approaches to achieve availability: single-master or multi-master. Note that pretty much any database can be highly available for eventually consistent reads at all times assuming part of the cluster is running. The really interesting part of availability is whether the system is available for writes, and whether it’s available for consistent reads.

Single Master

In this type of data store, there is a single master that owns each object in the database and multiple slaves that have eventually consistent copies of objects. This master is the only node that can process write requests or strongly consistent read requests for an object. If this master node fails or is otherwise unavailable, the system must go through a leader election process to find a new master. During this election process, the objects hosted at the master are unavailable for writes or consistent reads. Most systems still allow eventually consistent reads from slaves even during failures.

Key Features

  • Enables strong consistency
  • Some unavailability during fail-overs

Multi-Master

There are multiple masters for a single object and all of them are writable simultaneously. A client must write to a quorem of available masters in order to write the object. This allows multiple nodes to be failed without losing the ability to write. However, during failures clients may fail writes if a quorum is not available, or you may have inconsistency if you write to less than a quorum or employ techniques like sloppy quorums.

Key Features

  • Enables high availability
  • Some inconsistency expected

Partitioning

Partitioning refers to how data is distributed across the cluster.

Range Based Partitioning

In Range Based Partitioning, contiguous ranges of values are stored together on nodes. This means that the system can easily support range query operations. However, it also means that load distribution may be focused on particular ranges of values. For example, if I have partitioned on a value with low cardinality, then I may have inefficient distribution of requests across partitions. However, it’s pretty easy to implement hash partitioning on top of range partitioning by simply using a hashed value as your key.

Key Features

  • Efficient range queries
  • Hash partitioning is easy to add

Hash based partitioning

In Hash Based Partitioning, objects are distributed across the cluster according to a consistent hashing function. This enables efficient distribution of work for writes and reads by primary key, but it also means that a range query must hit every node on the cluster.

Key Features

  • Good load distribution
  • Range queries are impossible or ineffiecient

Summary

Choosing the right NoSQL store requires you understanding your use case and the tradeoffs of the platform you select. Most people move to NoSQL because some aspect of their relational datastore is inadequate. It’s a useful exercise to think about what it is that you don’t like about your existing database and what it is you want to get from NoSQL. I find that it’s useful to think about this by asking the following questions:

  1. What does my data look like and what kind of queries do I want to run? Are range queries important?
  2. When I have failures, would I rather have consistency violations, or unavailbility?

Compare the answers to these questions to the categories above and see where you fit.

How to spread fear, uncertainty and doubt (FUD)

This is the first in a series of posts about FUD, the thought process behind creating it, and how to quickly identify and defend against it!

I want to be clear before we get started tho, FUD is a terrible marketing strategy as it relies on lies about your competitor as its core distinguishing characteristic.

What makes good FUD?

The goal of FUD is to create fear in the customer that choosing a product might be a bad idea.

  1. It creates a tangible fear of increased cost
  2. It taps into previous bad experiences
  3. It relies on plausible but untestable truths

In most businesses, the worst ideas are those that lose you lots of money. If you can convince the customer that choosing a certain product or technology has a high risk of losing them lots of money, this will create real impediment to the adoption of that technology.

The most effective fears are those that the customer has experienced before. If you can tie a high cost risk to some previous incident where the customer lost money, they are going to have a more visceral reaction. If you can’t tie into a previous pain of the customer, a 3rd party’s well publicized failure will do.

The longest lasting fears are those that cannot be tested or disproved. A fear is no good if the customer can get over it with a simple test or research and dispel it as myth. Ideally, the customer will hold this fear until after it is too late to make a different decision. At this point, your FUD has become truth in the eyes of the customers and you have won the deal.

Creating a tangible fear of increased cost

When looking at the cost of software systems, we can typically break things down into 3 groups of costs:

  • Capital Expenditures
  • Operational Expenditures
  • Development Costs

Capital Expenditures (CAPEX)

CAPEX is the amount of money the customer spends on hardware and software. Your goal is to suggest that your competitor’s solution is going to be more expensive. The bigger the delta between your solution and your competitor, the better.

The competitor’s solution:

  • requires more hardware than yours
  • requires more expensive hardware than yours (e.g. a Sun E10k vs. a Dell poweredge server)
  • can’t run in the cloud
  • needs expensive peripherals (SAN, NAS, Switches/Routers, etc..)

Operational Expenditures (OPEX)

OPEX is the amount of money the customer spends operating a solution once it’s implemented. Your goal is to suggest that the competitor’s solution is going to cost more once it’s set up than your own. Once again, the bigger the cost difference, the better.

Your operations team will:

  • spend lots of time fixing competitor’s solution when it breaks
  • need to hire expensive employees with rare skill sets to make competitor’s solution work
  • need a large number of employees to manage this in production

Development Cost

Development cost is the amount of money per feature spent on your engineering team working with the product. Your goal is to convince the customer that your competitor’s solution is going to decrease productivity and/or require skills that are missing from the development organization.

Your engineers will:

  • need to code some features by hand with competitor’s solution
  • be forced to deal with poorly designed and documented API’s
  • have a hard time learning your competitor’s technology
  • need to hire someone with skill X that you don’t already have

Tap into previous bad experiences

If your customer has had problems in the past, tapping into that pain can work wonders. Shipping a product late, or having a major production failure hurts a development organization and most organizations will adapt to try to ensure that never happens again. The more your fear taps into these previous failures, the more effective it will be.

Did the customer have a major outage recently? If you know the root cause of that outage, try to convince them that your competitor’s product is prone to that same kind of outage.

Did the customer ship a product late or missing key features? Try to convince the customer that your competitor’s product will slow down their development cycle.

Rely on plausible, but untestable truths

Fear is no good if your customer can get over it. The best fear to place is that which cannot be tested. If you tell a customer that an API is hard to use, they can pretty quickly debunk that by trying out the API and seeing that it’s actually not that hard.

The best FUD will remain untested until a system goes into production and you find out for real. For example, you can position your competitor as “it’s going to work really good in development, but once you run it at scale, X is going to happen”. The great thing about this argument is that it’s nearly impossible for most customers to test something at production scale without choosing that product and actually running it into production. For most organizations, at this point they’ve already committed to the solution and you can count it as a win.

How to fight FUD

When a competitor is using FUD against you, it can be really frustrating for all of the reasons outlined above. If well executed, you customer will have misconceptions about your product that cannot be overcome in a lab or a tech talk. Fighting FUD requires that you understand the emotional response of a customer’s fears and address them head on.

In the next post in this series, we’ll dig into how to fight FUD spread against your product. Stay tuned!

Schemas for schemaless databases

Most of the modern NoSQL databases have eschewed the traditional RDBMS schema for a schemaless design. Databases like MongoDB, CouchDB, HBase, and Riak all allow you to store arbitrary new fields in your database without having to change any configuration.

With this comes some great advantages. Development cycles and data management just go more quickly because there’s less code to change (I can just update my Java or Python code without reconfiguring my Database).

But there are still some challenges that a schema would make easier:

Validation

Today most NoSQL stores leave validation as an exercise for the reader. This means that in your application code, you need to write lots of defensive code & logic to make sure data is valid before you put it into the store.

Once it’s there, it’s very difficult to figure out if the data in your database is actually valid. Human errors, faulty software, or any number of defects or software upgrades could result in invalid data.

Validation is difficult, especially with document-oriented data stores. Traditional SQL schemas don’t really fit the bill for a few reasons:

  • Data is not stored in references, so a referential schema is more or less useless
  • SQL schemas are typically not “round-trip” compatible. In other words, I cannot generate a schema from my code, and then generate code from my schema
  • It’s difficult to retain the highly dynamic nature of document oriented stores in conjunction with a strict schema

A great validation engine for document oriented database would survive these challenges.

Multi-language development

If you’re writing clients to your data in multiple languages, you need to essentially recreate your schema in each language accessing your database. Modern tools like , , and , and even older tools like , , and provide smart workflows for dealing with multi-language environments because you can build a generic description of your data and generate language specific stubs for any environment you want to access it.

It would be great to have this ability for document oriented stores

Language neutral

Ideally a schema definition language would be external to the language being used to access the database. The schema should be the same regardless of which language I’m using to access the DB and let us work in whatever language is necessary for the job at hand

Type systems for add on tools

When building things like Map Reduce jobs or processing pipelines, it’s useful to be able to reason about the types of objects passing between phases in my pipeline. Jobs are significantly simpler if I can have some guarantees that, for example, each document contains specific fields so the system can validate objects before entering the pipeline.

Thoughts and next steps

I’ve been talking to about a system that would bridge some of these gaps, specifically for mongoDB. Look for some follow up posts where we expand on our thoughts here

Getting started with Play Framework, Scala and Casbah

I’ve been dorking around with the , and recently and I wanted to share my recent progress. I’m new to scala and play, so I am probably running afoul of some of the best practices out there. If you’ve got any advice for me after reading this post, please do share.

Here’s what we’re going to do in this tutorial:

  1. Set up a new play framework project using scala
  2. Add the dependencies so you can use Casbah
  3. Create a controller that lists / posts messages to MongoDB
  4. Create templates for the app
  5. Create routes for our new controller
  6. You win!

Set up a new play framework project using scala

bash$ play install scala
bash$ play new myCasbahDemo --with scala

Now you should have a new directory called “myCasbahDemo” populated with the template for a play app.

Add the dependencies so you can use Casbah

We need to modify the conf/dependencies.yml file to tell play how to load the casbah dependencies. Here’s my conf/dependencies.yml file


# Application dependencies
require:
    - play
    - play -> scala 0.9
    - com.mongodb.casbah -> casbah_2.8.1 2.1.2

repositories:
  - scalatools:
     type: iBiblio
     root: http://scala-tools.org/repo-releases/
     contains:
       - com.mongodb.casbah -> *
       - org.scalaj -> *

Now we can run

bash$ play dependencies

Play will fetch the casbah dependencies and install them in the local project.

Create a controller that lists / posts messages to MongoDB

I created a new controller in app/controllers/Messages.scala with the following content:

package controllers;

import play.mvc._;
import com.mongodb.casbah.Imports._
import scala.collection.JavaConverters._

object Messages extends Controller {

  val _mongoConn = MongoConnection()

  def index = {

    val msgs = _mongoConn("casbah_test")("test_data").find( "msg" $exists true $ne "" )
    val msgStrings = msgs.map( (obj: DBObject) => obj.getOrElse("msg","") )
    Template( 'msgStrings -> msgStrings.asJava )
  }

  def save(msg:String) = {
    val doc = MongoDBObject("msg" -> msg)
    _mongoConn("casbah_test")("test_data").save( doc )
    Redirect("/messages")
  }
}

Our controller has two methods: “index” and “save”.

Index grabs a list of messages from mongo, extracts the text, and renders them in the corresponding template (we’ll look at those in a moment).

There’s a bit of magic going on here. Play uses Groovy as its template language, but many Scala types don’t directly translate to groovy types. So you’ll notice these lines of code:

    val msgStrings = msgs.map( (obj: DBObject) => obj.getOrElse("msg","") )
    Template( 'msgStrings -> msgStrings.asJava )

First, we got back a cursor from our mongo query. So we use map to extract the “msg” attribute from each of the docs returned. This gives us a scala List. But the Groovy language currently used by Play templates do not know how to iterate over a Scala collection. In order to help programmers working with other JVM languages, Scala 2.8.1 + provide the scala.collection.JavaConverters library, which adds the asJava method to Scala Collections (And an equivalent asScala method to Java collections). By calling asJava, we wrap our List in a Java compatible object that can be iterated.

We are working to provide an add on to Casbah or a patch to Play to make this easier in the future. In the mean time, be sure to include scala.collection.JavaConverters and convert your scala types to java types before calling your template.

Save accepts a new string message from the client and saves it to the collection before redirecting the user back to the message list template.

Note that I’m opening a connection to MongoDB in the controller. This isn’t a great design choice as this connection can be re-used by other controllers. In a future post, i’m going to add a real model layer and abstract the connection to mongoDB out. But for the time being, this will suffice.

Create templates for the app

There’s just one template for my app, a simple page with a form field for submitting a new message, followed by a list of the existing messages. My template is in app/views/Messages/index.html, following the play pattern.


#{extends 'main.html' /}
#{set title:'Home' /}

<form action="@{Messages.save()}" method="POST"/>
  <input type="text" name="msg"/>
  <input type="submit" value="Add message" />
</form>

<ul>
  #{list items:msgStrings, as:'mess' }
  <li>${ mess }</li>
  #{/list}
</ul>

Create a route for our new controller

in conf/routes, we need to add a route to our new controller. Here’s what mine looks like:


# Routes
# This file defines all application routes (Higher priority routes first)
# ~~~~

# Home page
GET     /                                       Messages.index
POST    /                                       Messages.save

Try it out!

First off, make sure that mongod is running on your localhost (we used the default constructor of the MongoDB connection which means it will look for mongod on localhost on the default ports.

bash$ play run

Wait for the app to startup, then point your browser at localhost:9000

And bam! You’ve got your first play + scala + casbah app up and running!

You can also check out the .
